CM CBT Plain Trolley
- 1⁄4 Ton (Metric Rated)
- Manual/Push Trolley
- Fits Hook Mounted Hoists
The CM CBT Plain Trolley is an economical choice and accepts most hook mounted hoists. The trolley features steel wrap around side plates, dual tread wheels and lifetime lubricated shielded ball bearings. All of the CBTs features combine to ensure you a trolley that is smooth rolling, versatile and reliable.
Features & Benefits
- Rated Loads from 1⁄4 to 1⁄2 Ton (Metric Rated)
- Excellent Low Cost Choice for Manual and Powered Hoists.
- Designed to Provide Superior Performance and Long, Efficient Service.
- Universal Hanging Clevis Accepts Most Hook Mounted Hoists.
- Trolley Easily Adjusts to Fit Any Beam Flange Within Range of Adjustment, Up to an 8.7″ Flange Width
- Wrap-Around Side Plates – Lugs Provide Additional Security to Increase Operator Safety and Act as Bumpers to Protect Wheels
- Dual Wheel Tread Wheels Will Fit Either Tapered or Flat Beam Flange Within Range of Adjustment
- Wheels Include Permanently Lubricated, Shielded Ball Bearings for Long Life and Low Maintenance.
- Lifetime Warranty
CM CBT Plain Trolley
| Capacity | Model | Beam Height | I-Beam Width | Min Radius Curve | Wheel Tread Diameter |
| 1⁄4 Ton | CBTP-0025 | 4–24" | 2–8.7" | 27" | 2.36" |
| 1⁄2 Ton | CBTP-0050 | 4–24" | 2–8.7" | 27" | 2.36" |
| 1 Ton | CBTP-0100 | 5–24" | 2.3–8.7" | 36" | 2.36" |
| 11⁄2 Ton | CBTP-0150 | 6–24" | 2.3–8.7" | 45" | 3.15" |
| 2 Ton | CBTP-0200 | 6–24" | 2.3–8.7" | 45" | 3.15" |
| 3 Ton | CBTP-0300 | 8–24" | 3–8.7" | 55" | 4.41" |
| 5 Ton | CBTP-0500 | 10–24" | 3.5–8.7" | 70" | 4.92" |
